SECTION 3. COMPOSITION/INFORMATION ON INGREDIENTS
3.1 Substances / mixture: Sodium Metal Chloride Battery Composition: CAS Number: Not specified Cases: Plastic Material Not dangerous.
Sodium Metal Chloride Cell:
Hazardous ingredients | CAS | % |
|---|---|---|
β"-Alumina (Solid Electrolyte) | 12005-48-0 | 17 – 20 |
NaAlCl4 | 7784-16-9 | 17 – 19 |
Ni (powder) | 7440-02-0 | 17 – 19 |
NaCl | 7647-14-5 | 10 – 13 |
Na | 7440-23-5 | 0.5 – 1.2 |
FeCl2 | 7758-94-3 | 0 – 1 |
Fe | 7439-89-6 | 1 – 3 |
FeS | 1317-37-9 | 0.5 – 0.7 |
NaF | 7681-49-4 | 0.5 – 0.7 |
NaI | 7681-82-5 | 0.1 – 0.2 |
Potentially dangerous constituents for a single cell: Single Cell (ML3X) | CAS | EINECS | Classification | Pictograms, Signal Word | Single Cell | ||
|---|---|---|---|---|---|---|---|
100%SOC* Weight (%) | 0% SOC* Weight (%) | ||||||
β"-Alumina (Solid Electrolyte) | 12005-48-0 | 234-467-9 | not classified | -- | 17 - 20 | 17 - 20 | |
NaAlCl4 | 7784-16-9 | 232-050-6 | Skin Corr. 1B H314 EUH014 | Danger
| 17 - 19 | 17 - 19 | |
Ni (powder) | 7440-02-0 | 231-111-4 | Skin Sens. 1 H317 Carc. 2 H351 STOT RE 1 H372 Aquatic Chronic 3 H412 | Danger
| 14 - 16 | 17 - 19 | |
NaCl | 7647-14-5 | 231-598-3 | Not classified | -- | 0 | 10 - 13 | |
NiCl2 | 7718-54-9 | 231-743-0 | Acute Tox. 3 H301 Skin Irrit. 2 H315 Skin Sens. 1 H317 Acute Tox. 3 H331 Resp. Sens. 1 H334 Muta. 2 H341 STOT RE 1 H372 Aquatic Acute 1 H400 Aquatic Chronic 1 H410 Carc. 1A H350i Repr. 1B H360D | Danger
| 6 - 9 | 0 | |
Na | 7440-23-5 | 231-132-9 | Water-react. 1 H260 Skin Corr. 1B H314 EUH014 | Danger
| 5 - 7 | 0.5 -1.2 | |
FeCl2 | 7758-94-3 | 231-843-4 | Met. Corr. 1 H290 Acute Tox. 4 H302 Eye Dam. 1 H318 | Danger
| 4 - 6 | 0 - 1 | |
Fe | 7439-89-6 | 231-096-4 | Not classified | -- | 0 | 1 - 3 | |
FeS | 1317-37-9 | 215-268-6 | Not classified | -- | 0.5 – 0.7 | 0.5 – 0.7 | |
NaF | 7681-49-4 | 231-667-8 | Acute Tox. 3 H301 Skin Irrit. 2 H315 Eye Irrit. 2 H319 EUH032 | Danger
| 0.5 – 0.7 | 0.5 – 0.7 | |
NaI | 7681-82-5 | 231-679-3 | Skin Irrit. 2 H315 Eye Irrit. 2 H319 Aquatic Acute 1 H400 | Warning | 0.1 – 0.2 | 0.1 – 0.2 | |
SOC = state of charge
Single Cell | ||
|---|---|---|
100%SOC* Weight (%) | 0% SOC* Weight (%) |
Current Collector (g) Nickel | 7 - 8 | 7 - 8 |
Carbon Felt (g) | 0.10 – 0.15 | 0.10 – 0.15 |
Shims (g) Iron | 4.0 – 4.5 | 4.0 – 4.5 |
Metal Case Iron | 13 - 15 | 13 - 15 |
